Plan Summary
-
Stories
1
-
Bedrooms
3
-
Bathrooms
2
-
Garage
2 car
-
Width x Length
57'8" x 40'0"
-
First Floor Sq Ft
1527
-
Total AC Sq Ft
1527
-
Total Under Roof Sq Ft
2136
"ORDERING " ANY OF OUR ARCHITECT HOUSE PLANS IS AS "SIMPLE" AS "1-2-3" - JUST FOLLOW THE "THREE" EASY STEPS BELOW!!!
Plan Description
This lovely 1,527 sq. ft., Mediterranean home floor plan demands a second glance. Entry through the porch takes you and your guests into the generous family room, perfect for entertaining. A well-equipped kitchen is conveniently found just off of the great room. The master suite is nestled in the back of this design while the second bedroom occupies the front, creating privacy for all family members. Concrete block exterior construction. Purchase this lovely home floor plan today.
Dimensions
- Width x Length 57'8" x 40'0"
- Height 18'-0
- Stories 1/
Garage
- Number of Cars 2
- Attached No
- Location Right
Wall Construction
- Interior Metal stud
- Exterior CMU Block
Insulation
- CMU Wall R-4.1
- Wood Wall R-19
- Framed Wall R-11
Bedrooms
- Actual 3
- Possible 0
- Total 3
Bathrooms
- Full 2
- Half 0
- Total 2
Elevation
- Finishes Stucco
- Master Bedroom Location 1
- Utility Location 1
Features
- Fireplace No
- Elevator No
- Pool No
Instant Download Only
1 Study Set Price: $150
- (Extra Sets: $50)
- More Information
PDF Files Price: $1150
- (Extra Sets: $150)
- More Information
CAD Disk Price: $1650
- (Extra Sets: $500)
- More Information
Hard Copies (Shipped)
Base Price: $650
- (Extra Sets: $50)
- More Information
3 Sets Price: $750
- (Extra Sets: $50)
- More Information
5 Sets Price: $850
- (Extra Sets: $50)
- More Information
8 Sets Price: $1000
- (Extra Sets: $50)
- More Information
Reproducible Vellum Price: $1150
- (Extra Sets: $150)
- More Information
Foundation Type
- Type Monolithic
- Option 0
Floor System
- Type 0
- Spacing 0
- Subfloor 0
- Thickness 0
Roof System
- Type Wood trusses
- Options 0
Additional Information
- Roof Pitch 5:12
- Roof: Live Load 30
- Roof: Dead Load 25
- Floor: Live Load 40
- Floor: Dead Load 25
- Roof Material C. Tile
- Wind Speed 140
First Floor
- Primary Living Cathedral
- Secondary Living Vaulted
- Primary Bedrooms Vaulted
- Secondary Bedrooms 9'-4
- Bathrooms 9'-4
- Common Areas 9'-4
Exterior
- Garage 0
- Covered Entry 0
- Covered Patio 0
- Covered Balcony 0
Total AC Sq Ft
- First Floor AC 1527
- Total AC 1527
Total Under Roof Sq Ft
- Garage 380
- Covered Entry 37
- Covered Patio 192
- Covered Balconies 0
- Total Under Roof 2136
