Plan Summary
-
Stories
1
-
Bedrooms
3
-
Bathrooms
2
-
Garage
2 car
-
Width x Length
35' x 66'
-
First Floor Sq Ft
1744
-
Total AC Sq Ft
1744
-
Total Under Roof Sq Ft
2192
"ORDERING " ANY OF OUR ARCHITECT HOUSE PLANS IS AS "SIMPLE" AS "1-2-3" - JUST FOLLOW THE "THREE" EASY STEPS BELOW!!!
Plan Description
This luxurious, one-story Mediterranean home has three bedrooms, two bathrooms and a two-car garage. This design features optional elevations. The exquisite French doors with arched transom accent the entrance. The master suite is large and has a huge walk-in closet. A large combined living room and dining room maximize space.
Dimensions
- Width x Length 35' x 66'
- Height 16'-9
- Stories 1/
Garage
- Number of Cars 2
- Attached Yes
- Location Left
Wall Construction
- Interior Metal stud
- Exterior CMU
Insulation
- CMU Wall R-4.1
- Wood Wall R-19
- Framed Wall R-11
Bedrooms
- Actual 3
- Possible 0
- Total 3
Bathrooms
- Full 2
- Half 0
- Total 2
Elevation
- Finishes Stucco
- Master Bedroom Location 1
- Utility Location 1
Features
- Fireplace No
- Elevator No
- Pool No
Instant Download Only
1 Study Set Price: $150
- (Extra Sets: $50)
- More Information
PDF Files Price: $1150
- (Extra Sets: $150)
- More Information
CAD Disk Price: $1650
- (Extra Sets: $500)
- More Information
Hard Copies (Shipped)
Base Price: $650
- (Extra Sets: $50)
- More Information
3 Sets Price: $750
- (Extra Sets: $50)
- More Information
5 Sets Price: $850
- (Extra Sets: $50)
- More Information
8 Sets Price: $1000
- (Extra Sets: $50)
- More Information
Reproducible Vellum Price: $1150
- (Extra Sets: $150)
- More Information
Foundation Type
- Type Monolithic
- Option 0
Floor System
- Type 0
- Spacing 0
- Subfloor 0
- Thickness 0
Roof System
- Type Wood trusses
- Options 0
Additional Information
- Roof Pitch 5:12
- Roof: Live Load 30
- Roof: Dead Load 25
- Floor: Live Load 40
- Floor: Dead Load 25
- Roof Material C. tile
- Wind Speed 140
First Floor
- Primary Living 9'-3
- Secondary Living 9'-3
- Primary Bedrooms 9'-3
- Secondary Bedrooms 9'-3
- Bathrooms 9'-3
- Common Areas 0
Exterior
- Garage 9'-3
- Covered Entry 12'-0
- Covered Patio 0
- Covered Balcony 0
Total AC Sq Ft
- First Floor AC 1744
- Total AC 1744
Total Under Roof Sq Ft
- Garage 404
- Covered Entry 44
- Covered Patio 0
- Covered Balconies 0
- Total Under Roof 2192
