PLAN SUMMARY
-
Stories
2
-
Bedrooms
3
-
Bathrooms
4
-
Garage
4 car
-
Width x Length:
96' " x 68' 9"
-
First Floor Sq Ft
1,837 Sq. Ft.
-
Second Floor Sq Ft
1,068 Sq. Ft.
-
Total AC Sq Ft
2,905 Sq. Ft.
-
Total Under Roof Sq Ft
5,863 Sq. Ft.
$0.00
Plan Description
This 2,905 sq. ft., two-story Mediterranean-style home floor plan has three bedrooms, three bathrooms plus a cabana bathroom and a four-car garage with aircraft parking. This home is luxurious inside and out! This model features a grand covered entrance, balconies and patio. A large central great room is flanked by covered patios. The large island kitchen with an eating bar and breakfast area opens to the dining room and great room. This design boasts a truly luxurious master suite with large “His and Hers” walk-in closets, stylish tray ceiling and a regal master bath leading to a private balcony. The star attraction of this design is the hangar. High ceilings and two volume spaces make this design feel “larger than life.” Purchase and download this luxurious two story home floor plan today.
Dimensions
-
Width x Length
96' " x 68' 9"
-
Height
24'-9
-
Stories
2/
Garage
-
Number of Cars
4
-
Attached
Yes
-
Location
Right
Wall Construction
-
Interior
Metal stud
-
Exterior
CMU
-
Insulation
-
CMU Wall
R-4.1
-
Wood Wall
R-19
-
Framed Wall
R-11
Bedrooms
-
Actual
3
-
Possible
0
-
Total
3
Bathrooms
-
Full
3
-
Half
0
-
Total
4
Elevation
-
Finishes
Stucco
-
Master Bedroom Location
2
-
Utility Location
2
Features
-
Fireplace
No
-
Elevator
No
-
Pool
No
Instant Download Only
1 Study Set Price: $150
PDF Files Price: $1250
CAD Disk Price: $1850
Reverse PDF Price: $1500
Reverse CAD Price: $2100
Study Set Reverse Price: $200
Hard Copies (Shipped)
Base Price: $750
3 Sets Price: $850
5 Sets Price: $950
8 Sets Price: $1100
Reproducible Vellum Price: $1250
Base – Not for Construction Price: $750
3 Sets (Reverse) Price: $1100
5 Sets (Reverse) Price: $1200
8 Sets (Reverse) Price: $1350
Reproducible Vellum (Reverse) Price: $1500
Foundation Type
-
Type
Monolithic
-
Option
0
Floor System
-
Type
0
-
Spacing
0
-
Subfloor
0
-
Thickness
0
Roof System
-
Type
Wood trusses
-
Options
0
Additional Information
-
Roof Pitch
5:12
-
Roof: Live Load
30
-
Roof: Dead Load
25
-
Floor: Live Load
40
-
Floor: Dead Load
25
-
Roof Material
C. tile
-
Wind Speed
140
First Floor
-
Primary Living
17'-6
-
Secondary Living
8'-0
-
Primary Bedrooms
8'-0
-
Secondary Bedrooms
8'-0
-
Bathrooms
8'-0
-
Common Areas
8'-0
Second Floor
-
Primary Bedrooms
8' to 10'
-
Secondary Bedrooms
8'
-
Bathrooms
8'
-
Common Areas
8'
Exterior
-
Garage
12'-8
-
Covered Entry
18'-2
-
Covered Patio
9'-8
-
Covered Balcony
8'-0
Total AC Sq Ft
-
First Floor AC
1837
-
Second Floor AC
1068
-
Total AC
2905
Total Under Roof Sq Ft
-
Garage
2592
-
Covered Entry
89
-
Covered Patio
206
-
Covered Balconies
71
-
Total Under Roof
5863
