House Plans
Plan Summary
-
Stories
2
-
Bedrooms
5
-
Bathrooms
3
-
Garage
2 car
-
Width x Length
39'10" x 59'2"
-
First Floor Sq Ft
1662
-
Second Floor Sq Ft
1392
-
Total AC Sq Ft
3058
-
Total Under Roof Sq Ft
3580
"ORDERING " ANY OF OUR ARCHITECT HOUSE PLANS IS AS "SIMPLE" AS "1-2-3" - JUST FOLLOW THE "THREE" EASY STEPS BELOW!!!
This plan is restricted.
Please call 1-855-PLANS-123 (1-954-736-4696) for more information
Plan Description
This luxurious 3,058 sq. ft., two-story, home floor plan has five bedrooms, three and one-half bathrooms and a two-car garage. The kitchen has a cafe area and located adjacent to the family room. This is a well thought-out and charming home plan. The home is a Contemporary open layout. The exclusive master suite has “His and Hers” walk-in closets, a sitting area and luxurious master bath creating at the second floor a compact design with the other bedrooms. Purchase this home floor plan today.
Dimensions
- Width x Length 39'10" x 59'2"
- Height 30'-8
- Stories 2/
Garage
- Number of Cars 2
- Attached Yes
- Location Left
Wall Construction
- Interior Metal stud
- Exterior CMU
Insulation
- CMU Wall R-4.1
- Wood Wall R-19
- Framed Wall R-11
Bedrooms
- Actual 5
- Possible 0
- Total 5
Bathrooms
- Full 3
- Half 0
- Total 3
Elevation
- Finishes Stucco
- Master Bedroom Location 2
- Utility Location 1
Features
- Fireplace No
- Elevator No
- Pool No
Instant Download Only
1 Study Set Price: $150
- (Extra Sets: $50)
- More Information
PDF Files Price: $1350
- (Extra Sets: $150)
- More Information
CAD Disk Price: $2050
- (Extra Sets: $500)
- More Information
Hard Copies (Shipped)
Base Price: $850
- (Extra Sets: $50)
- More Information
3 Sets Price: $950
- (Extra Sets: $50)
- More Information
5 Sets Price: $1050
- (Extra Sets: $50)
- More Information
8 Sets Price: $1200
- (Extra Sets: $50)
- More Information
Reproducible Vellum Price: $1350
- (Extra Sets: $150)
- More Information
Foundation Type
- Type Monolithic
- Option 0
Floor System
- Type wood truss
- Spacing 0
- Subfloor 0
- Thickness 0
Roof System
- Type Wood trusses
- Options 0
Additional Information
- Roof Pitch 5:12
- Roof: Live Load 30
- Roof: Dead Load 25
- Floor: Live Load 40
- Floor: Dead Load 25
- Roof Material C. tile
- Wind Speed 140
First Floor
- Primary Living 10'-0
- Secondary Living
- Primary Bedrooms 0
- Secondary Bedrooms 0
- Bathrooms 10'-0
- Common Areas 10'-0
Second Floor
- Primary Bedrooms 9'-0
- Secondary Bedrooms 9'-0
- Bathrooms 9'-0
- Common Areas 0
Exterior
- Garage 9'-0
- Covered Entry 10'-0
- Covered Patio 0
- Covered Balcony 0
Total AC Sq Ft
- First Floor AC 1662
- Second Floor AC 1392
- Total AC 3058
Total Under Roof Sq Ft
- Garage 361
- Covered Entry 161
- Covered Patio 0
- Covered Balconies 0
- Total Under Roof 3580
