Plan Summary
-
Stories
2
-
Bedrooms
4
-
Bathrooms
3
-
Garage
2 car
-
Width x Length
33' x 90'
-
First Floor Sq Ft
1695
-
Second Floor Sq Ft
1389
-
Total AC Sq Ft
3084
-
Total Under Roof Sq Ft
3795
"ORDERING " ANY OF OUR ARCHITECT HOUSE PLANS IS AS "SIMPLE" AS "1-2-3" - JUST FOLLOW THE "THREE" EASY STEPS BELOW!!!
This plan is restricted.
Please call 1-855-PLANS-123 (1-954-736-4696) for more information
Plan Description
This two-story, 3,084 sq. ft., Mediterranean-style home plan features four bedrooms, three full bathrooms plus a powder room and a two-car garage. A formal foyer invites guests into the living room. The large island kitchen with an eating bar and cafe opens to a family room. A large Great room open to a two-story back patio. There is an exclusive master suite with “His and Hers” walk-in closets and a luxurious master bath. Get this home floor plan today.
Dimensions
- Width x Length 33' x 90'
- Height 29'-4
- Stories 2/
Garage
- Number of Cars 2
- Attached Yes
- Location Right
Wall Construction
- Interior Metal stud
- Exterior CMU
Insulation
- CMU Wall R-4.1
- Wood Wall R-19
- Framed Wall R-11
Bedrooms
- Actual 4
- Possible 0
- Total 4
Bathrooms
- Full 3
- Half 1
- Total 3
Elevation
- Finishes Stucco
- Master Bedroom Location 1
- Utility Location 2
Features
- Fireplace No
- Elevator No
- Pool No
Instant Download Only
1 Study Set Price: $150
- (Extra Sets: $50)
- More Information
PDF Files Price: $1350
- (Extra Sets: $150)
- More Information
CAD Disk Price: $2050
- (Extra Sets: $500)
- More Information
Hard Copies (Shipped)
Base Price: $850
- (Extra Sets: $50)
- More Information
3 Sets Price: $950
- (Extra Sets: $50)
- More Information
5 Sets Price: $1050
- (Extra Sets: $50)
- More Information
8 Sets Price: $1200
- (Extra Sets: $50)
- More Information
Reproducible Vellum Price: $1350
- (Extra Sets: $150)
- More Information
Foundation Type
- Type Monolithic
- Option 0
Floor System
- Type 0
- Spacing 0
- Subfloor 0
- Thickness 0
Roof System
- Type Wood trusses
- Options 0
Additional Information
- Roof Pitch 5:12
- Roof: Live Load 30
- Roof: Dead Load 25
- Floor: Live Load 40
- Floor: Dead Load 25
- Roof Material C. tile
- Wind Speed 140
First Floor
- Primary Living 10'-0
- Secondary Living 10'-0
- Primary Bedrooms 10'-0
- Secondary Bedrooms 0
- Bathrooms 10'-0
- Common Areas 10'-0
Second Floor
- Primary Bedrooms 9'-0
- Secondary Bedrooms 9'-0
- Bathrooms 9'-0
- Common Areas 0
Exterior
- Garage 10'-0
- Covered Entry 10'-0
- Covered Patio 23'-0
- Covered Balcony 0
Total AC Sq Ft
- First Floor AC 1695
- Second Floor AC 1389
- Total AC 3084
Total Under Roof Sq Ft
- Garage 500
- Covered Entry 79
- Covered Patio 132
- Covered Balconies 0
- Total Under Roof 3795
