House Plans
Plan Summary
-
Stories
2
-
Bedrooms
4
-
Bathrooms
4
-
Garage
2 car
-
Width x Length
40' x 75'
-
First Floor Sq Ft
1596
-
Second Floor Sq Ft
1496
-
Total AC Sq Ft
3092
-
Total Under Roof Sq Ft
3712
"ORDERING " ANY OF OUR ARCHITECT HOUSE PLANS IS AS "SIMPLE" AS "1-2-3" - JUST FOLLOW THE "THREE" EASY STEPS BELOW!!!
This plan is restricted.
Please call 1-855-PLANS-123 (1-954-736-4696) for more information
Plan Description
This 3,092 sq. ft., two-story Colonial-style waterfront home floor plan has four bedrooms, four full bathrooms and a two-car garage. The large island kitchen with a huge breakfast area opens to a family room and a combination of dinning and living room. There is an exclusive master suite with “His and Hers” walk-in closets and a luxurious master bath. This design is compact and great for family life. Buy this home floor plan today.
Dimensions
- Width x Length 40' x 75'
- Height 31'-5
- Stories 2/
Garage
- Number of Cars 2
- Attached Yes
- Location Left
Wall Construction
- Interior Metal stud
- Exterior CMU
Insulation
- CMU Wall R-4.1
- Wood Wall R-19
- Framed Wall R-11
Bedrooms
- Actual 4
- Possible 0
- Total 4
Bathrooms
- Full 4
- Half 0
- Total 4
Elevation
- Finishes Stucco
- Master Bedroom Location 2
- Utility Location 1
Features
- Fireplace No
- Elevator No
- Pool No
Instant Download Only
1 Study Set Price: $150
- (Extra Sets: $50)
- More Information
PDF Files Price: $1350
- (Extra Sets: $150)
- More Information
CAD Disk Price: $2050
- (Extra Sets: $500)
- More Information
Hard Copies (Shipped)
Base Price: $850
- (Extra Sets: $50)
- More Information
3 Sets Price: $950
- (Extra Sets: $50)
- More Information
5 Sets Price: $1050
- (Extra Sets: $50)
- More Information
8 Sets Price: $1200
- (Extra Sets: $50)
- More Information
Reproducible Vellum Price: $1350
- (Extra Sets: $150)
- More Information
Foundation Type
- Type Monolithic
- Option 0
Floor System
- Type wood truss
- Spacing 0
- Subfloor 0
- Thickness 0
Roof System
- Type Wood trusses
- Options 0
Additional Information
- Roof Pitch 7:12
- Roof: Live Load 30
- Roof: Dead Load 25
- Floor: Live Load 40
- Floor: Dead Load 25
- Roof Material C. tile
- Wind Speed 140
First Floor
- Primary Living 10'-0
- Secondary Living 10'-0
- Primary Bedrooms 10'-0
- Secondary Bedrooms 0
- Bathrooms 10'-0
- Common Areas 10'-0
Second Floor
- Primary Bedrooms 9'-0
- Secondary Bedrooms 9'-0
- Bathrooms 9'-0
- Common Areas 0
Exterior
- Garage 8'-4
- Covered Entry 10'-0
- Covered Patio 0
- Covered Balcony 9'-0
Total AC Sq Ft
- First Floor AC 1596
- Second Floor AC 1496
- Total AC 3092
Total Under Roof Sq Ft
- Garage 414
- Covered Entry 103
- Covered Patio 0
- Covered Balconies 103
- Total Under Roof 3712
In Association With:
1-855-PLANS-123
1-954-736-4696
