Plan Summary
-
Stories
1
-
Bedrooms
4
-
Bathrooms
3
-
Garage
3 car
-
Width x Length
64'11" x 76'2"
-
First Floor Sq Ft
3161
-
Total AC Sq Ft
3161
-
Total Under Roof Sq Ft
4341
"ORDERING " ANY OF OUR ARCHITECT HOUSE PLANS IS AS "SIMPLE" AS "1-2-3" - JUST FOLLOW THE "THREE" EASY STEPS BELOW!!!
This plan is restricted.
Please call 1-855-PLANS-123 (1-954-736-4696) for more information
Plan Description
This luxurious, one-story, 3,161 sq. ft., Mediterranean-style home floor plan has four bedrooms, three bathrooms and a three-car garage. Each bedroom suite has access to a bathroom. The ultimate master suite features “His and Hers” walk-in closets, stylish tray ceilings, a luxurious master bathroom and is close to a private study. This plan is very well-suited for a narrow lot. Download this home floor plan today.
Dimensions
- Width x Length 64'11" x 76'2"
- Height 20'-5
- Stories 1/
Garage
- Number of Cars 3
- Attached Yes
- Location Left
Wall Construction
- Interior Metal stud
- Exterior CMU
Insulation
- CMU Wall R-4.1
- Wood Wall R-19
- Framed Wall R-11
Bedrooms
- Actual 4
- Possible 0
- Total 4
Bathrooms
- Full 3
- Half 0
- Total 3
Elevation
- Finishes Stucco
- Master Bedroom Location 1
- Utility Location 1
Features
- Fireplace No
- Elevator No
- Pool No
Instant Download Only
1 Study Set Price: $150
- (Extra Sets: $50)
- More Information
PDF Files Price: $1350
- (Extra Sets: $150)
- More Information
CAD Disk Price: $2050
- (Extra Sets: $500)
- More Information
Hard Copies (Shipped)
Base Price: $850
- (Extra Sets: $50)
- More Information
3 Sets Price: $950
- (Extra Sets: $50)
- More Information
5 Sets Price: $1050
- (Extra Sets: $50)
- More Information
8 Sets Price: $1200
- (Extra Sets: $50)
- More Information
Reproducible Vellum Price: $1350
- (Extra Sets: $150)
- More Information
Foundation Type
- Type Monolithic
- Option 0
Floor System
- Type 0
- Spacing 0
- Subfloor 0
- Thickness 0
Roof System
- Type Wood trusses
- Options 0
Additional Information
- Roof Pitch 5:12
- Roof: Live Load 30
- Roof: Dead Load 25
- Floor: Live Load 40
- Floor: Dead Load 25
- Roof Material C. tile
- Wind Speed 140
First Floor
- Primary Living 12'-0
- Secondary Living 12'-0
- Primary Bedrooms 12'-0
- Secondary Bedrooms 9'-4
- Bathrooms 9'-4
- Common Areas 0
Exterior
- Garage 9'-4
- Covered Entry 14'-1
- Covered Patio 0
- Covered Balcony 0
Total AC Sq Ft
- First Floor AC 3161
- Total AC 3161
Total Under Roof Sq Ft
- Garage 633
- Covered Entry 255
- Covered Patio 292
- Covered Balconies 0
- Total Under Roof 4341
In Association With:
1-855-PLANS-123
1-954-736-4696
