Plan Summary
-
Stories
1
-
Bedrooms
3
-
Bathrooms
3
-
Garage
2 car
-
Width x Length
40' x 114'
-
First Floor Sq Ft
3180
-
Total AC Sq Ft
3180
-
Total Under Roof Sq Ft
3670
"ORDERING " ANY OF OUR ARCHITECT HOUSE PLANS IS AS "SIMPLE" AS "1-2-3" - JUST FOLLOW THE "THREE" EASY STEPS BELOW!!!
Plan Description
This luxurious, 3,180 sq. ft., one-story, Mediterranean-style home floor plan has three bedrooms, three bathrooms and a two-car garage. There is a large adjoining workshop in the two-car garage! Each bedroom suite has its own bathroom. The ultimate master suite features “His and Hers” walk-in closets, stylish tray ceilings, a private study and a luxurious master bathroom. This home plan is very well-suited for a narrow lot. Pick up this luxurious single story home floor plan today.
Dimensions
- Width x Length 40' x 114'
- Height 19'-8
- Stories 1/
Garage
- Number of Cars 2
- Attached Yes
- Location Right
Wall Construction
- Interior Metal stud
- Exterior CMU
Insulation
- CMU Wall R-4.1
- Wood Wall R-19
- Framed Wall R-11
Bedrooms
- Actual 3
- Possible 0
- Total 3
Bathrooms
- Full 3
- Half 0
- Total 3
Elevation
- Finishes Stucco
- Master Bedroom Location 1
- Utility Location 1
Features
- Fireplace No
- Elevator No
- Pool No
Instant Download Only
1 Study Set Price: $150
- (Extra Sets: $50)
- More Information
PDF Files Price: $1350
- (Extra Sets: $150)
- More Information
CAD Disk Price: $2050
- (Extra Sets: $500)
- More Information
Hard Copies (Shipped)
Base Price: $850
- (Extra Sets: $50)
- More Information
3 Sets Price: $950
- (Extra Sets: $50)
- More Information
5 Sets Price: $1050
- (Extra Sets: $50)
- More Information
8 Sets Price: $1200
- (Extra Sets: $50)
- More Information
Reproducible Vellum Price: $1350
- (Extra Sets: $150)
- More Information
Foundation Type
- Type Monolithic
- Option 0
Floor System
- Type 0
- Spacing 0
- Subfloor 0
- Thickness 0
Roof System
- Type Wood trusses
- Options 0
Additional Information
- Roof Pitch 5:12
- Roof: Live Load 30
- Roof: Dead Load 25
- Floor: Live Load 40
- Floor: Dead Load 25
- Roof Material C. tile
- Wind Speed 140
First Floor
- Primary Living 11'-10
- Secondary Living 11'-10
- Primary Bedrooms 11'-10
- Secondary Bedrooms 9'-10
- Bathrooms 9'-10
- Common Areas 0
Exterior
- Garage 7'-10
- Covered Entry 14'-3
- Covered Patio 0
- Covered Balcony 0
Total AC Sq Ft
- First Floor AC 3180
- Total AC 3180
Total Under Roof Sq Ft
- Garage 453
- Covered Entry 37
- Covered Patio 0
- Covered Balconies 0
- Total Under Roof 3670
In Association With:
1-855-PLANS-123
1-954-736-4696
