PLAN SUMMARY
-
Stories
2
-
Bedrooms
5
-
Bathrooms
4
-
Garage
2 car
-
Width x Length:
80' " x 50' "
-
First Floor Sq Ft
2,112 Sq. Ft.
-
Second Floor Sq Ft
1,191 Sq. Ft.
-
Total AC Sq Ft
3,303 Sq. Ft.
-
Total Under Roof Sq Ft
4,097 Sq. Ft.
$0.00
Plan Description
This 3,303 sq. ft., two-story home floor plan has five bedrooms, three and one-half bathrooms and a two-car garage. This design offers optional elevations. The towering covered entrance makes a great first impression. The formal foyer is extremely inviting to guests and leads to the living room, flanked by a dining room and parlor. A gourmet island kitchen with an eating bar, breakfast nook and pantry opens to the family room. This model includes a luxurious master suite with large walk-in closets, sitting area and a regal master bath opening to a covered lanai. You’ll love this design if you seek a spacious home including private areas for solitude. One of the highlights of this design is the large family room that opens to a covered lanai. Purchased and download this home floor plan today.
Dimensions
-
Width x Length
80' " x 50' "
-
Height
28'-7
-
Stories
2/
Garage
-
Number of Cars
2
-
Attached
Yes
-
Location
Left
Wall Construction
-
Interior
Metal stud
-
Exterior
CMU
-
Insulation
-
CMU Wall
R-4.1
-
Wood Wall
R-19
-
Framed Wall
R-11
Bedrooms
-
Actual
5
-
Possible
0
-
Total
5
Bathrooms
-
Full
3
-
Half
0
-
Total
4
Elevation
-
Finishes
Stucco
-
Master Bedroom Location
1
-
Utility Location
2
Features
-
Fireplace
No
-
Elevator
No
-
Pool
No
Instant Download Only
1 Study Set Price: $150
PDF Files Price: $1350
CAD Disk Price: $2050
Reverse PDF Price: $1600
Reverse CAD Price: $2300
Study Set Reverse Price: $200
Hard Copies (Shipped)
Base Price: $850
3 Sets Price: $950
5 Sets Price: $1050
8 Sets Price: $1200
Reproducible Vellum Price: $1350
Base – Not for Construction Price: $850
3 Sets (Reverse) Price: $1150
5 Sets (Reverse) Price: $1300
8 Sets (Reverse) Price: $1450
Reproducible Vellum (Reverse) Price: $1600
Foundation Type
-
Type
Monolithic
-
Option
0
Floor System
-
Type
Steel joist
-
Spacing
24
-
Subfloor
Concrete
-
Thickness
3/4
Roof System
-
Type
Wood trusses
-
Options
0
Additional Information
-
Roof Pitch
5:12
-
Roof: Live Load
30
-
Roof: Dead Load
25
-
Floor: Live Load
40
-
Floor: Dead Load
25
-
Roof Material
C. tile
-
Wind Speed
140
First Floor
-
Primary Living
10'-0
-
Secondary Living
10'-0
-
Primary Bedrooms
10'-0
-
Secondary Bedrooms
0
-
Bathrooms
10'-0
-
Common Areas
0
Second Floor
-
Primary Bedrooms
0
-
Secondary Bedrooms
9'-4
-
Bathrooms
9'-4
-
Common Areas
0
Exterior
-
Garage
8'-0
-
Covered Entry
10'-8
-
Covered Patio
10'-0
-
Covered Balcony
0
Total AC Sq Ft
-
First Floor AC
2112
-
Second Floor AC
1191
-
Total AC
3303
Total Under Roof Sq Ft
-
Garage
513
-
Covered Entry
82
-
Covered Patio
199
-
Covered Balconies
0
-
Total Under Roof
4097
