Plan Summary
-
Stories
1
-
Bedrooms
3
-
Bathrooms
3
-
Garage
3 car
-
Width x Length
78'2" x 100'0"
-
First Floor Sq Ft
3455
-
Total AC Sq Ft
3455
-
Total Under Roof Sq Ft
5241
"ORDERING " ANY OF OUR ARCHITECT HOUSE PLANS IS AS "SIMPLE" AS "1-2-3" - JUST FOLLOW THE "THREE" EASY STEPS BELOW!!!
Plan Description
This beautiful, one-story home features three bedrooms, two and one-half bathrooms plus a cabana, a three-car garage with an extra work area, a grand covered entry and a rear patio. The floor plan provides a formal foyer with high ceiling flanked by a dining room and study, a formal dining room and an exclusive master suite featuring “His and Hers” walk-in closets, stylish tray ceilings, sitting area and a luxurious master bathroom with access to a large covered patio, all combined making this truly a luxurious design.
Dimensions
- Width x Length 78'2" x 100'0"
- Height 23'-1
- Stories 1/
Garage
- Number of Cars 3
- Attached Yes
- Location Left
Wall Construction
- Interior Metal Stud
- Exterior CMU Block
Insulation
- CMU Wall R-4.1
- Wood Wall R-19
- Framed Wall R-11
Bedrooms
- Actual 3
- Possible 0
- Total 3
Bathrooms
- Full 3
- Half 1
- Total 3
Elevation
- Finishes Stucco
- Master Bedroom Location 1
- Utility Location 1
Features
- Fireplace No
- Elevator No
- Pool No
Instant Download Only
1 Study Set Price: $150
- (Extra Sets: $50)
- More Information
PDF Files Price: $1350
- (Extra Sets: $150)
- More Information
CAD Disk Price: $2050
- (Extra Sets: $500)
- More Information
Hard Copies (Shipped)
Base Price: $850
- (Extra Sets: $50)
- More Information
3 Sets Price: $950
- (Extra Sets: $50)
- More Information
5 Sets Price: $1050
- (Extra Sets: $50)
- More Information
8 Sets Price: $1200
- (Extra Sets: $50)
- More Information
Reproducible Vellum Price: $1350
- (Extra Sets: $150)
- More Information
Foundation Type
- Type Monolithic
- Option 0
Floor System
- Type 0
- Spacing 0
- Subfloor 0
- Thickness 0
Roof System
- Type Wood trusses
- Options 0
Additional Information
- Roof Pitch 5:12
- Roof: Live Load 30
- Roof: Dead Load 25
- Floor: Live Load 40
- Floor: Dead Load 25
- Roof Material 0
- Wind Speed 140
First Floor
- Primary Living 12' to 14'
- Secondary Living 12'
- Primary Bedrooms 10' to 11'-4
- Secondary Bedrooms 9'
- Bathrooms 9'
- Common Areas 12' to 13'
Exterior
- Garage 9'
- Covered Entry 14'
- Covered Patio 12'
- Covered Balcony 0
Total AC Sq Ft
- First Floor AC 3455
- Total AC 3455
Total Under Roof Sq Ft
- Garage 765
- Covered Entry 146
- Covered Patio 875
- Covered Balconies 0
- Total Under Roof 5241
