PLAN SUMMARY
-
Stories
1
-
Bedrooms
4
-
Bathrooms
3
-
Garage
3 car
-
Width x Length:
102' 3" x 104' 9"
-
First Floor Sq Ft
3,568 Sq. Ft.
-
Total AC Sq Ft
3,568 Sq. Ft.
-
Total Under Roof Sq Ft
6,112 Sq. Ft.
$0.00
Plan Description
This 3,568 sq. ft., one-story home floor plan has four bedrooms, three bathrooms and a three-car garage plus cart parking. The unique design features a large utility room offering additional storage. The Contemporary open layout plan gives a spacious appeal to this home. The large island in the kitchen with an eating bar and breakfast nook opens to the family room. The model offers a truly luxurious master suite featuring “His and Hers” walk-in closets, a sitting area and luxurious master bath with access to a large covered patio. Purchase this home floor plan today.
Dimensions
-
Width x Length
102' 3" x 104' 9"
-
Height
19'-1
-
Stories
1/
Garage
-
Number of Cars
3
-
Attached
No
-
Location
Right
Wall Construction
-
Interior
Metal stud
-
Exterior
CMU
-
Insulation
-
CMU Wall
R-4.1
-
Wood Wall
R-19
-
Framed Wall
R-11
Bedrooms
-
Actual
4
-
Possible
0
-
Total
4
Bathrooms
-
Full
3
-
Half
0
-
Total
3
Elevation
-
Finishes
Stucco
-
Master Bedroom Location
1
-
Utility Location
1
Features
-
Fireplace
No
-
Elevator
No
-
Pool
No
Instant Download Only
1 Study Set Price: $150
PDF Files Price: $1400
CAD Disk Price: $2100
Reverse PDF Price: $1650
Reverse CAD Price: $2350
Study Set Reverse Price: $200
Hard Copies (Shipped)
Base Price: $900
3 Sets Price: $1000
5 Sets Price: $1100
8 Sets Price: $1250
Reproducible Vellum Price: $1400
Base – Not for Construction Price: $900
3 Sets (Reverse) Price: $1250
5 Sets (Reverse) Price: $1350
8 Sets (Reverse) Price: $1500
Reproducible Vellum (Reverse) Price: $1650
Foundation Type
-
Type
Monolithic
-
Option
0
Floor System
-
Type
0
-
Spacing
0
-
Subfloor
0
-
Thickness
0
Roof System
-
Type
Wood trusses
-
Options
0
Additional Information
-
Roof Pitch
5:12
-
Roof: Live Load
30
-
Roof: Dead Load
25
-
Floor: Live Load
40
-
Floor: Dead Load
25
-
Roof Material
C. tile
-
Wind Speed
140
First Floor
-
Primary Living
12'
-
Secondary Living
12'
-
Primary Bedrooms
9'
-
Secondary Bedrooms
9'
-
Bathrooms
9'
-
Common Areas
9'
Exterior
-
Garage
9'
-
Covered Entry
14'-0
-
Covered Patio
9'
-
Covered Balcony
0
Total AC Sq Ft
-
First Floor AC
3568
-
Total AC
3568
Total Under Roof Sq Ft
-
Garage
1305
-
Covered Entry
636
-
Covered Patio
603
-
Covered Balconies
0
-
Total Under Roof
6112
