Plan Summary
-
Stories
1
-
Bedrooms
4
-
Bathrooms
4
-
Garage
3 car
-
Width x Length
69'6" x 90'0"
-
First Floor Sq Ft
3725
-
Total AC Sq Ft
3725
-
Total Under Roof Sq Ft
5017
"ORDERING " ANY OF OUR ARCHITECT HOUSE PLANS IS AS "SIMPLE" AS "1-2-3" - JUST FOLLOW THE "THREE" EASY STEPS BELOW!!!
This plan is restricted.
Please call 1-855-PLANS-123 (1-954-736-4696) for more information
Plan Description
This 3,725 sq. ft., Mediterranean-style home floor plan has four bedrooms, maid’s room, office, den, sitting room, four full bathrooms plus a cabana bathroom and a three-car garage. High ceilings make this design feel “larger than life”. The large covered front porch makes an attractive addition to this home. The luxurious master suite has a walk-in closet, a sitting area and a regal master bath. The large island in the kitchen has an eating bar and breakfast area adjacent to the family room. The living room is large and centrally located opening to the covered patio. Get this Mediterranean-style home floor plan today.
Dimensions
- Width x Length 69'6" x 90'0"
- Height 21'-0
- Stories 1/
Garage
- Number of Cars 3
- Attached Yes
- Location Left
Wall Construction
- Interior Metal stud
- Exterior CMU
Insulation
- CMU Wall R-4.1
- Wood Wall R-19
- Framed Wall R-11
Bedrooms
- Actual 4
- Possible 1
- Total 4
Bathrooms
- Full 4
- Half 1
- Total 4
Elevation
- Finishes Stucco
- Master Bedroom Location 1
- Utility Location 1
Features
- Fireplace No
- Elevator No
- Pool No
Instant Download Only
1 Study Set Price: $150
- (Extra Sets: $50)
- More Information
PDF Files Price: $1400
- (Extra Sets: $150)
- More Information
CAD Disk Price: $2100
- (Extra Sets: $500)
- More Information
Hard Copies (Shipped)
Base Price: $900
- (Extra Sets: $50)
- More Information
3 Sets Price: $1000
- (Extra Sets: $50)
- More Information
5 Sets Price: $1100
- (Extra Sets: $50)
- More Information
8 Sets Price: $1250
- (Extra Sets: $50)
- More Information
Reproducible Vellum Price: $1400
- (Extra Sets: $150)
- More Information
Foundation Type
- Type Monolithic
- Option 0
Floor System
- Type 0
- Spacing 0
- Subfloor 0
- Thickness 0
Roof System
- Type Wood trusses
- Options 0
Additional Information
- Roof Pitch 5:12
- Roof: Live Load 30
- Roof: Dead Load 25
- Floor: Live Load 40
- Floor: Dead Load 25
- Roof Material C. tile
- Wind Speed 140
First Floor
- Primary Living 12'-0
- Secondary Living 12'-0
- Primary Bedrooms 10'-0
- Secondary Bedrooms 10'-0
- Bathrooms 10'-0
- Common Areas 0
Exterior
- Garage 10'-0
- Covered Entry 15'-4
- Covered Patio 12'-0
- Covered Balcony 0
Total AC Sq Ft
- First Floor AC 3725
- Total AC 3725
Total Under Roof Sq Ft
- Garage 675
- Covered Entry 120
- Covered Patio 497
- Covered Balconies 0
- Total Under Roof 5017
In Association With:
1-855-PLANS-123
1-954-736-4696
