House Plans
Plan Summary
-
Stories
2
-
Bedrooms
4
-
Bathrooms
4
-
Garage
2 car
-
Width x Length
52'8" x 72'0"
-
First Floor Sq Ft
1863
-
Second Floor Sq Ft
2006
-
Total AC Sq Ft
3869
-
Total Under Roof Sq Ft
5027
"ORDERING " ANY OF OUR ARCHITECT HOUSE PLANS IS AS "SIMPLE" AS "1-2-3" - JUST FOLLOW THE "THREE" EASY STEPS BELOW!!!
Plan Description
This 3,869 sq. ft., two-story, Mediterranean-style waterfront home floor plan has four bedrooms, three full bathrooms plus a half bathroom, cabana bath and a two-car garage. This classic Florida-style home includes a grand covered entry. High ceilings and two volume spaces make this design feel “larger than life.” A gourmet island kitchen with an eating bar, cafe and pantry opens to a family room. You’ll love this design if you’re looking for a home with a spacious feel while providing many private spaces. The den offers a private area for entertaining or simple solitude. The formal dining room displays tray ceilings. The family room opens to a covered patio with summer kitchen. You’ll be impressed by the foyer that opens to a large central area with the living room adjacent to the kitchen and family room. This model includes a luxurious master suite with “His and Hers” walk-in closets and a regal master bath with spa tub opening to a private covered balcony. Download this Mediterranean style home floor plan today.
Dimensions
- Width x Length 52'8" x 72'0"
- Height 30'-10
- Stories 2/
Garage
- Number of Cars 2
- Attached Yes
- Location Left
Wall Construction
- Interior Metal stud
- Exterior CMU
Insulation
- CMU Wall R-4.1
- Wood Wall R-19
- Framed Wall R-11
Bedrooms
- Actual 4
- Possible 0
- Total 4
Bathrooms
- Full 4
- Half 1
- Total 4
Elevation
- Finishes Stucco
- Master Bedroom Location 2
- Utility Location 1
Features
- Fireplace No
- Elevator No
- Pool Yes
Instant Download Only
1 Study Set Price: $150
- (Extra Sets: $50)
- More Information
PDF Files Price: $1400
- (Extra Sets: $150)
- More Information
CAD Disk Price: $2100
- (Extra Sets: $500)
- More Information
Hard Copies (Shipped)
Base Price: $900
- (Extra Sets: $50)
- More Information
3 Sets Price: $1000
- (Extra Sets: $50)
- More Information
5 Sets Price: $1100
- (Extra Sets: $50)
- More Information
8 Sets Price: $1250
- (Extra Sets: $50)
- More Information
Reproducible Vellum Price: $1400
- (Extra Sets: $150)
- More Information
Foundation Type
- Type Monolithic
- Option 0
Floor System
- Type Pre-engineered wood
- Spacing 24
- Subfloor wood
- Thickness 3/4
Roof System
- Type Wood trusses
- Options 0
Additional Information
- Roof Pitch 5:12
- Roof: Live Load 30
- Roof: Dead Load 25
- Floor: Live Load 40
- Floor: Dead Load 25
- Roof Material C. tile
- Wind Speed 140
First Floor
- Primary Living 21'-10
- Secondary Living 9'-10
- Primary Bedrooms
- Secondary Bedrooms 0
- Bathrooms 9'-2
- Common Areas 10'-6
Second Floor
- Primary Bedrooms 9'-4
- Secondary Bedrooms 9'-4
- Bathrooms 9'-4
- Common Areas 9'-4
Exterior
- Garage 0
- Covered Entry 10'-6
- Covered Patio 0
- Covered Balcony 0
Total AC Sq Ft
- First Floor AC 1863
- Second Floor AC 2006
- Total AC 3869
Total Under Roof Sq Ft
- Garage 643
- Covered Entry 117
- Covered Patio 161
- Covered Balconies 0
- Total Under Roof 5027
