PLAN SUMMARY
-
Stories
2
-
Bedrooms
4
-
Bathrooms
4
-
Garage
3 car
-
Width x Length:
69' 9" x 62' 8"
-
First Floor Sq Ft
2,463 Sq. Ft.
-
Second Floor Sq Ft
1,826 Sq. Ft.
-
Total AC Sq Ft
4,289 Sq. Ft.
-
Total Under Roof Sq Ft
5,645 Sq. Ft.
$0.00
Plan Description
This luxurious, 4,289 sq. ft., two-story, Mediterranean-style home features four bedrooms, three and one-half bathrooms, a cabana bathroom and a three-car garage. This is an outstanding design for a large family. A towering, covered entrance gives this unique home design palatial curb appeal. The first floor offers a guest suite with a private entrance. Paneled front doors with transom above adds elegance to the entrance. The gourmet kitchen with cafe opening to a family room creates a spectacular entertaining feel. The family room opens to a covered patio with a summer kitchen. There is a luxurious master bedroom suite with large walk-in closets, a sitting area and a regal master bath that opens onto a private, covered balcony. A large living room has two-story ceilings with a wet bar and fireplace. This is an outstanding design to select for a large family, entertaining and private solitude. Get this home plan design today.
Dimensions
-
Width x Length
69' 9" x 62' 8"
-
Height
33'
-
Stories
2/
Garage
-
Number of Cars
3
-
Attached
Yes
-
Location
Left
Wall Construction
-
Interior
Metal stud
-
Exterior
CMU
-
Insulation
-
CMU Wall
R-4.1
-
Wood Wall
R-19
-
Framed Wall
R-11
Bedrooms
-
Actual
4
-
Possible
0
-
Total
4
Bathrooms
-
Full
4
-
Half
0
-
Total
4
Elevation
-
Finishes
Stucco
-
Master Bedroom Location
2
-
Utility Location
1
Features
-
Fireplace
Yes
-
Elevator
No
-
Pool
Yes
Instant Download Only
1 Study Set Price: $150
PDF Files Price: $1500
CAD Disk Price: $2300
Reverse PDF Price: $1750
Reverse CAD Price: $2550
Study Set Reverse Price: $200
Hard Copies (Shipped)
Base Price: $1000
3 Sets Price: $1100
5 Sets Price: $1200
8 Sets Price: $1350
Reproducible Vellum Price: $1500
Base – Not for Construction Price: $1000
3 Sets (Reverse) Price: $1350
5 Sets (Reverse) Price: $1450
8 Sets (Reverse) Price: $1600
Reproducible Vellum (Reverse) Price: $1750
Foundation Type
-
Type
Monolithic
-
Option
0
Floor System
-
Type
Steel joist
-
Spacing
24
-
Subfloor
Concrete
-
Thickness
3
Roof System
-
Type
Wood trusses
-
Options
0
Additional Information
-
Roof Pitch
5:12
-
Roof: Live Load
30
-
Roof: Dead Load
25
-
Floor: Live Load
40
-
Floor: Dead Load
25
-
Roof Material
C. tile
-
Wind Speed
140
First Floor
-
Primary Living
23'-8
-
Secondary Living
11' to 12'
-
Primary Bedrooms
-
Secondary Bedrooms
11'
-
Bathrooms
9'-4
-
Common Areas
11'
Second Floor
-
Primary Bedrooms
9'-4
-
Secondary Bedrooms
9'-4
-
Bathrooms
9'-4
-
Common Areas
9'-4
Exterior
-
Garage
0
-
Covered Entry
0
-
Covered Patio
0
-
Covered Balcony
0
Total AC Sq Ft
-
First Floor AC
2463
-
Second Floor AC
1826
-
Total AC
4289
Total Under Roof Sq Ft
-
Garage
605
-
Covered Entry
145
-
Covered Patio
385
-
Covered Balconies
0
-
Total Under Roof
5645
