Plan Summary
-
Stories
2
-
Bedrooms
5
-
Bathrooms
5
-
Garage
3 car
-
Width x Length
57'6" x 96'0"
-
First Floor Sq Ft
2358
-
Second Floor Sq Ft
2179
-
Total AC Sq Ft
4537
-
Total Under Roof Sq Ft
6446
"ORDERING " ANY OF OUR ARCHITECT HOUSE PLANS IS AS "SIMPLE" AS "1-2-3" - JUST FOLLOW THE "THREE" EASY STEPS BELOW!!!
Plan Description
This luxurious two-story 4,537 sq. ft., home plan features four bedrooms plus a guest suite, three and one-half bathrooms, a cabana bathroom and a three-car garage. The grand covered entry is accented by a custom arched transom and sidelights. The grand covered entrance gives this home floor plan spectacular curb appeal. This interior court house layout provides spectacular views to the pool. The guest bedroom suite has a private entrance. The home model includes a luxurious master suite with walk-in closets, a sitting area and regal master bath opening onto a covered porch. Stairs are very luxurious and a highlight this design. Columns and arches provide strong curb appeal at the exterior. Exquisite French doors feature arched transom to accent the covered entrance. The huge island kitchen has an eating bar and breakfast nook opening to the large family room. A covered patio, balcony and breezeway accent this house design. There is a first floor VIP suite with a private entrance. The family room opens to a covered patio making a perfect setting for entertaining or simple solitude. The living room is spectacular with raised ceiling and a wet bar. On the first floor, the multipurpose room can become an ideal library. Purchase this home floor plan today.
Dimensions
- Width x Length 57'6" x 96'0"
- Height 28'-7
- Stories 2/
Garage
- Number of Cars 3
- Attached No
- Location Left
Wall Construction
- Interior Metal stud
- Exterior CMU
Insulation
- CMU Wall R-4.1
- Wood Wall R-19
- Framed Wall R-11
Bedrooms
- Actual 5
- Possible 0
- Total 5
Bathrooms
- Full 3
- Half 0
- Total 5
Elevation
- Finishes Stucco
- Master Bedroom Location 2
- Utility Location 2
Features
- Fireplace No
- Elevator No
- Pool Yes
Instant Download Only
1 Study Set Price: $150
- (Extra Sets: $50)
- More Information
PDF Files Price: $1600
- (Extra Sets: $150)
- More Information
CAD Disk Price: $2400
- (Extra Sets: $500)
- More Information
Hard Copies (Shipped)
Base Price: $1100
- (Extra Sets: $50)
- More Information
3 Sets Price: $1200
- (Extra Sets: $50)
- More Information
5 Sets Price: $1300
- (Extra Sets: $50)
- More Information
8 Sets Price: $1450
- (Extra Sets: $50)
- More Information
Reproducible Vellum Price: $1600
- (Extra Sets: $150)
- More Information
Foundation Type
- Type Monolithic
- Option 0
Floor System
- Type Steel joist
- Spacing 16
- Subfloor Concrete
- Thickness 3
Roof System
- Type Wood trusses
- Options 0
Additional Information
- Roof Pitch 5:12
- Roof: Live Load 30
- Roof: Dead Load 25
- Floor: Live Load 40
- Floor: Dead Load 25
- Roof Material C. tile
- Wind Speed 140
First Floor
- Primary Living 9'-10
- Secondary Living 9'-10
- Primary Bedrooms 9'-10
- Secondary Bedrooms 9'-10
- Bathrooms 9'-10
- Common Areas 9'-10
Second Floor
- Primary Bedrooms 0
- Secondary Bedrooms 0
- Bathrooms 0
- Common Areas 0
Exterior
- Garage 9'-10
- Covered Entry 13'-4
- Covered Patio 9'-10
- Covered Balcony 9'-10
Total AC Sq Ft
- First Floor AC 2358
- Second Floor AC 2179
- Total AC 4537
Total Under Roof Sq Ft
- Garage 649
- Covered Entry 633
- Covered Patio 216
- Covered Balconies 411
- Total Under Roof 6446
