PLAN SUMMARY
-
Stories
2
-
Bedrooms
5
-
Bathrooms
6
-
Garage
2 car
-
Width x Length:
54' 9" x 75' "
-
First Floor Sq Ft
2,526 Sq. Ft.
-
Second Floor Sq Ft
2,253 Sq. Ft.
-
Total AC Sq Ft
4,779 Sq. Ft.
-
Total Under Roof Sq Ft
5,853 Sq. Ft.
$0.00
Plan Description
This two-story, 4,779 sq. ft., Mediterranean-style waterfront home floor plan features five bedrooms, five and one-half bathrooms plus a cabana bath and two-car garage. French doors with arched transom accent the covered entrance. Columns and arches provide strong curb appeal. The luxurious exterior displays magnificent covered balconies, terrace and a patio. A large living room with high ceilings and dining room are combined, highlighting this home design. The large family room opens onto a covered patio. The gourmet island kitchen has an eating bar, cafe and pantry. The den offers a private area for entertaining or simple solitude. An exclusive master suite has a luxurious adjacent master bath. You’ll love this design if you seek a home that truly offers space, elegance and private areas to relax and unwind! Purchase this waterfront home plan today.
Dimensions
-
Width x Length
54' 9" x 75' "
-
Height
31'
-
Stories
2/
Garage
-
Number of Cars
2
-
Attached
Yes
-
Location
Right and Left
Wall Construction
-
Interior
Metal stud
-
Exterior
CMU
-
Insulation
-
CMU Wall
R-4.1
-
Wood Wall
R-19
-
Framed Wall
R-11
Bedrooms
-
Actual
5
-
Possible
1
-
Total
5
Bathrooms
-
Full
6
-
Half
1
-
Total
6
Elevation
-
Finishes
Stucco
-
Master Bedroom Location
2
-
Utility Location
2
Features
-
Fireplace
No
-
Elevator
No
-
Pool
Yes
Instant Download Only
1 Study Set Price: $150
PDF Files Price: $1600
CAD Disk Price: $2400
Reverse PDF Price: $1850
Reverse CAD Price: $2650
Study Set Reverse Price: $200
Hard Copies (Shipped)
Base Price: $1100
3 Sets Price: $1200
5 Sets Price: $1300
8 Sets Price: $1450
Reproducible Vellum Price: $1600
Base – Not for Construction Price: $1100
3 Sets (Reverse) Price: $1450
5 Sets (Reverse) Price: $1550
8 Sets (Reverse) Price: $1700
Reproducible Vellum (Reverse) Price: $1850
Foundation Type
-
Type
Monolithic
-
Option
0
Floor System
-
Type
Wood
-
Spacing
24
-
Subfloor
wood
-
Thickness
3/4
Roof System
-
Type
Wood trusses
-
Options
0
Additional Information
-
Roof Pitch
5:12
-
Roof: Live Load
30
-
Roof: Dead Load
25
-
Floor: Live Load
40
-
Floor: Dead Load
25
-
Roof Material
C. tile
-
Wind Speed
140
First Floor
-
Primary Living
20'-10
-
Secondary Living
10'-8
-
Primary Bedrooms
-
Secondary Bedrooms
10'-8
-
Bathrooms
10'-8
-
Common Areas
10'-8
Second Floor
-
Primary Bedrooms
9'-2
-
Secondary Bedrooms
9'-2
-
Bathrooms
9'-2
-
Common Areas
9'-2
Exterior
-
Garage
10'-0
-
Covered Entry
10'-8
-
Covered Patio
10'-8
-
Covered Balcony
12'-4
Total AC Sq Ft
-
First Floor AC
2526
-
Second Floor AC
2253
-
Total AC
4779
Total Under Roof Sq Ft
-
Garage
652
-
Covered Entry
104
-
Covered Patio
202
-
Covered Balconies
116
-
Total Under Roof
5853
