Plan Summary
-
Stories
1
-
Bedrooms
6
-
Bathrooms
5
-
Garage
3 car
-
Width x Length
106'1" x 122'1"
-
First Floor Sq Ft
5084
-
Total AC Sq Ft
5084
-
Total Under Roof Sq Ft
7663
"ORDERING " ANY OF OUR ARCHITECT HOUSE PLANS IS AS "SIMPLE" AS "1-2-3" - JUST FOLLOW THE "THREE" EASY STEPS BELOW!!!
Plan Description
This beautiful, one-story, classic, Spanish Mediterranean-style home features six bedrooms, five and one-half bathrooms, a three-car garage, grand covered entry with an eight-foot high front door with arched transom. Spectacular columns and arches provide a strong curb appeal. The well-designed home features a large living room complete with a wet bar. The huge island kitchen has an eating bar and opens to the family room and formal dining room. The design includes a truly luxurious master suite with exceptionally large “His and Hers” walk-in closets and stylish tray ceiling that definitely add luxury to this design.
Dimensions
- Width x Length 106'1" x 122'1"
- Height 23'-0
- Stories 1/
Garage
- Number of Cars 3
- Attached No
- Location Left
Wall Construction
- Interior Metal Stud
- Exterior CMU Block
Insulation
- CMU Wall R-4.1
- Wood Wall R-19
- Framed Wall R-11
Bedrooms
- Actual 6
- Possible 0
- Total 6
Bathrooms
- Full 5
- Half 1
- Total 5
Elevation
- Finishes Stucco
- Master Bedroom Location 1
- Utility Location 1
Features
- Fireplace No
- Elevator No
- Pool No
Instant Download Only
1 Study Set Price: $150
- (Extra Sets: $50)
- More Information
PDF Files Price: $1700
- (Extra Sets: $150)
- More Information
CAD Disk Price: $2600
- (Extra Sets: $500)
- More Information
Hard Copies (Shipped)
Base Price: $1200
- (Extra Sets: $50)
- More Information
3 Sets Price: $1300
- (Extra Sets: $50)
- More Information
5 Sets Price: $1400
- (Extra Sets: $50)
- More Information
8 Sets Price: $1550
- (Extra Sets: $50)
- More Information
Reproducible Vellum Price: $1700
- (Extra Sets: $150)
- More Information
Foundation Type
- Type monolithic
- Option 0
Floor System
- Type 0
- Spacing 0
- Subfloor 0
- Thickness 0
Roof System
- Type wood trusses
- Options 0
Additional Information
- Roof Pitch 5:12
- Roof: Live Load 30
- Roof: Dead Load 25
- Floor: Live Load 40
- Floor: Dead Load 25
- Roof Material C. Tile
- Wind Speed 140
First Floor
- Primary Living 12'-0
- Secondary Living 12'-0
- Primary Bedrooms 10'-0
- Secondary Bedrooms 10'-0
- Bathrooms 10'-0
- Common Areas 10'-0
Exterior
- Garage 9'-0
- Covered Entry 12'-0
- Covered Patio 12'-0
- Covered Balcony 0
Total AC Sq Ft
- First Floor AC 5084
- Total AC 5084
Total Under Roof Sq Ft
- Garage 855
- Covered Entry 63
- Covered Patio 1661
- Covered Balconies 0
- Total Under Roof 7663
In Association With:
1-855-PLANS-123
1-954-736-4696
