House Plans
Plan Summary
-
Stories
2
-
Bedrooms
6
-
Bathrooms
5
-
Garage
2 car
-
Width x Length
59'10" x 62'2"
-
First Floor Sq Ft
2536
-
Second Floor Sq Ft
2696
-
Total AC Sq Ft
5232
-
Total Under Roof Sq Ft
5956
"ORDERING " ANY OF OUR ARCHITECT HOUSE PLANS IS AS "SIMPLE" AS "1-2-3" - JUST FOLLOW THE "THREE" EASY STEPS BELOW!!!
This plan is restricted.
Please call 1-855-PLANS-123 (1-954-736-4696) for more information
Plan Description
This 5,233 sq. ft., two-story, Spanish Mediterranean-style manor home plan features six bedrooms, four and one-half bathrooms and a two-car garage. Columns and arches exude “majesty” in its appearance both inside and out. This home design offers an enormous amount of living space. A “dream” chef’s kitchen is complete and centrally located with a breakfast area, dinning room, family room, living room and foyer. The luxurious master suite feature enormous walk-in closets, tray ceilings and a regal master bath. The exquisite arrangement of the covered entry and formal foyer makes a dramatic first impression with the spiral stair. Get this home plan design today.
Dimensions
- Width x Length 59'10" x 62'2"
- Height 28'-3
- Stories 2/
Garage
- Number of Cars 2
- Attached Yes
- Location Right
Wall Construction
- Interior Metal stud
- Exterior CMU
Insulation
- CMU Wall R-4.1
- Wood Wall R-19
- Framed Wall R-11
Bedrooms
- Actual 6
- Possible 0
- Total 6
Bathrooms
- Full 4
- Half 0
- Total 5
Elevation
- Finishes Stucco
- Master Bedroom Location 2
- Utility Location 2
Features
- Fireplace No
- Elevator No
- Pool No
Instant Download Only
1 Study Set Price: $150
- (Extra Sets: $50)
- More Information
PDF Files Price: $1700
- (Extra Sets: $150)
- More Information
CAD Disk Price: $2600
- (Extra Sets: $500)
- More Information
Hard Copies (Shipped)
Base Price: $1200
- (Extra Sets: $50)
- More Information
3 Sets Price: $1300
- (Extra Sets: $50)
- More Information
5 Sets Price: $1400
- (Extra Sets: $50)
- More Information
8 Sets Price: $1550
- (Extra Sets: $50)
- More Information
Reproducible Vellum Price: $1700
- (Extra Sets: $150)
- More Information
Foundation Type
- Type Monolithic
- Option 0
Floor System
- Type Wood truss
- Spacing 24
- Subfloor wood
- Thickness 3/4
Roof System
- Type Wood trusses
- Options 0
Additional Information
- Roof Pitch 5:12
- Roof: Live Load 30
- Roof: Dead Load 25
- Floor: Live Load 40
- Floor: Dead Load 25
- Roof Material C. tile
- Wind Speed 140
First Floor
- Primary Living 9'-0
- Secondary Living 9'-0
- Primary Bedrooms 0
- Secondary Bedrooms 9'-0
- Bathrooms 9'-0
- Common Areas 9'-0
Second Floor
- Primary Bedrooms 9'-0
- Secondary Bedrooms 9'-0
- Bathrooms 9'-0
- Common Areas 0
Exterior
- Garage 9'-6
- Covered Entry 9'-6
- Covered Patio 9'-6
- Covered Balcony 0
Total AC Sq Ft
- First Floor AC 2536
- Second Floor AC 2696
- Total AC 5232
Total Under Roof Sq Ft
- Garage 640
- Covered Entry 84
- Covered Patio 0
- Covered Balconies 0
- Total Under Roof 5956
