Plan Summary
-
Stories
2
-
Bedrooms
5
-
Bathrooms
5
-
Garage
3 car
-
Width x Length
77'9" x 90'5"
-
First Floor Sq Ft
4126
-
Second Floor Sq Ft
1840
-
Total AC Sq Ft
5966
-
Total Under Roof Sq Ft
7188
"ORDERING " ANY OF OUR ARCHITECT HOUSE PLANS IS AS "SIMPLE" AS "1-2-3" - JUST FOLLOW THE "THREE" EASY STEPS BELOW!!!
Plan Description
This sprawling, beautiful, two-story, 5,966 sq. ft., Spanish-style manor offers an enormous amount of living space and amenities; five bedrooms, five bathrooms, a cabana and three-car garage. The home plan design has covered balconies and columns providing a majestic appearance and luxurious interior and exterior to the home. The exquisite arrangement of the covered entry and formal foyer make a dramatic first impression and inviting through a columned vestibule into the family room. The first story features a covered entrance with an eight-foot high French door with arched transom, a large living room with tray ceilings and stately fireplace. A library/den provides a cozy retreat for relaxation or to entertain. A chef’s “dream” kitchen with an island, eating bar and breakfast nook opens to the family room. The first story has a luxurious master suite with enormous walk-in closets, morning kitchen, tray ceilings and a regal master bathroom. Get this home floor plan today.
Dimensions
- Width x Length 77'9" x 90'5"
- Height 34'-0
- Stories 2/
Garage
- Number of Cars 3
- Attached Yes
- Location Left
Wall Construction
- Interior 0
- Exterior 0
Insulation
- CMU Wall R-4.1
- Wood Wall R-19
- Framed Wall R-11
Bedrooms
- Actual 5
- Possible 0
- Total 5
Bathrooms
- Full 5
- Half 1
- Total 5
Elevation
- Finishes Stucco
- Master Bedroom Location 1
- Utility Location 2
Features
- Fireplace Yes
- Elevator No
- Pool Yes
Instant Download Only
1 Study Set Price: $150
- (Extra Sets: $50)
- More Information
PDF Files Price: $1800
- (Extra Sets: $150)
- More Information
CAD Disk Price: $2700
- (Extra Sets: $500)
- More Information
Hard Copies (Shipped)
Base Price: $1300
- (Extra Sets: $50)
- More Information
3 Sets Price: $1400
- (Extra Sets: $50)
- More Information
5 Sets Price: $1500
- (Extra Sets: $50)
- More Information
8 Sets Price: $1650
- (Extra Sets: $50)
- More Information
Reproducible Vellum Price: $1800
- (Extra Sets: $150)
- More Information
Foundation Type
- Type Monolithic
- Option 0
Floor System
- Type concrete
- Spacing 0
- Subfloor Concrete
- Thickness 0
Roof System
- Type wood trusses
- Options 0
Additional Information
- Roof Pitch 5:12
- Roof: Live Load 30
- Roof: Dead Load 25
- Floor: Live Load 40
- Floor: Dead Load 25
- Roof Material C. Tile
- Wind Speed 140
First Floor
- Primary Living 14'-0
- Secondary Living 10'-0
- Primary Bedrooms 10'-0
- Secondary Bedrooms 0
- Bathrooms 10'-0
- Common Areas 0
Second Floor
- Primary Bedrooms 0
- Secondary Bedrooms 10'-0
- Bathrooms 10'-0
- Common Areas 10'-0
Exterior
- Garage 8'-7
- Covered Entry 0
- Covered Patio 0
- Covered Balcony 0
Total AC Sq Ft
- First Floor AC 4126
- Second Floor AC 1840
- Total AC 5966
Total Under Roof Sq Ft
- Garage 537
- Covered Entry 88
- Covered Patio 397
- Covered Balconies 200
- Total Under Roof 7188
