PLAN SUMMARY
-
Stories
2
-
Bedrooms
5
-
Bathrooms
5
-
Garage
4 car
-
Width x Length:
81' " x 94' 2"
-
First Floor Sq Ft
3,842 Sq. Ft.
-
Second Floor Sq Ft
2,213 Sq. Ft.
-
Total AC Sq Ft
6,055 Sq. Ft.
-
Total Under Roof Sq Ft
7,951 Sq. Ft.
$0.00
Plan Description
Two-story, 6,055 sq. ft., Mediterranean-style house plan features five bedrooms, four and one-half bathrooms, a cabana bathroom and three-car garage. The towering, covered entrance makes this home design luxurious at both the interior and exterior areas. Covered balconies and the eight-foot high French doors with arched transom accent the entrance. The den/library makes for a quiet retreat, perfect for relaxing. Columns and arches provide a strong curb appeal. The huge island kitchen with an eating bar opens to the family room. A luxurious master bedroom suite features large walk-in closets, a morning kitchen, tray ceilings and a regal master bath providing additional storage areas and opens onto a private balcony. The large living room features a fireplace. Get this Mediterranean-style home floor plan today.
Dimensions
-
Width x Length
81' " x 94' 2"
-
Height
31'
-
Stories
2/
Garage
-
Number of Cars
4
-
Attached
No
-
Location
Left and Right
Wall Construction
-
Interior
Metal stud
-
Exterior
CMU
-
Insulation
-
CMU Wall
R-4.1
-
Wood Wall
R-19
-
Framed Wall
R-11
Bedrooms
-
Actual
5
-
Possible
0
-
Total
5
Bathrooms
-
Full
5
-
Half
1
-
Total
5
Elevation
-
Finishes
Stucco
-
Master Bedroom Location
1
-
Utility Location
2
Features
-
Fireplace
Yes
-
Elevator
No
-
Pool
No
Instant Download Only
1 Study Set Price: $150
PDF Files Price: $1900
CAD Disk Price: $2900
Reverse PDF Price: $2150
Reverse CAD Price: $3150
Study Set Reverse Price: $200
Hard Copies (Shipped)
Base Price: $1400
3 Sets Price: $1500
5 Sets Price: $1600
8 Sets Price: $1750
Reproducible Vellum Price: $1900
Base – Not for Construction Price: $1400
3 Sets (Reverse) Price: $1750
5 Sets (Reverse) Price: $1850
8 Sets (Reverse) Price: $2000
Reproducible Vellum (Reverse) Price: $2150
Foundation Type
-
Type
concrete
-
Option
0
Floor System
-
Type
Supranos
-
Spacing
0
-
Subfloor
0
-
Thickness
0
Roof System
-
Type
Wood trusses
-
Options
0
Additional Information
-
Roof Pitch
5:12
-
Roof: Live Load
30
-
Roof: Dead Load
25
-
Floor: Live Load
40
-
Floor: Dead Load
25
-
Roof Material
S. tile
-
Wind Speed
140
First Floor
-
Primary Living
22'
-
Secondary Living
11'
-
Primary Bedrooms
-
Secondary Bedrooms
0
-
Bathrooms
10'
-
Common Areas
10' to 10'-8
Second Floor
-
Primary Bedrooms
0
-
Secondary Bedrooms
9'-6
-
Bathrooms
9'-6
-
Common Areas
9'-6
Exterior
-
Garage
10'-6
-
Covered Entry
23'-0
-
Covered Patio
24'-0
-
Covered Balcony
0
Total AC Sq Ft
-
First Floor AC
3842
-
Second Floor AC
2213
-
Total AC
6055
Total Under Roof Sq Ft
-
Garage
879
-
Covered Entry
254
-
Covered Patio
763
-
Covered Balconies
131
-
Total Under Roof
7951
