PLAN SUMMARY
-
Stories
2
-
Bedrooms
6
-
Bathrooms
7
-
Garage
3 car
-
Width x Length:
80' " x 77' "
-
First Floor Sq Ft
3,539 Sq. Ft.
-
Second Floor Sq Ft
3,140 Sq. Ft.
-
Total AC Sq Ft
6,679 Sq. Ft.
-
Total Under Roof Sq Ft
8,676 Sq. Ft.
$0.00
Plan Description
Two-story, 6,679 sq. ft., classic, Mediterranean-style waterfront home floor plan features seven bedrooms, six and one-half bathrooms, a cabana bathroom and three-car garage. Columns and arches make a majestic curb appeal. The towering, covered entrance and exquisite French doors with arched transom accent the entrance. The first story includes an added amenity of a VIP suite and maid’s room. This home has opulent, covered balconies and patio to add to the exterior attraction of this design. Stylish tray ceilings accent this exclusive home. A gourmet kitchen with an eating bar, cafe and pantry opens to a family room. A large living room displays two-story tray ceilings and a stately fireplace. There is a formal dining room for those special times of entertaining. This model includes a truly exclusive master suite with exceptionally large His-and-Hers walk-in closets, stylish tray ceiling, a sitting area, morning kitchen and luxurious master bath opening onto a private balcony. Get this classic Mediterranean-style home floor plan today.
Dimensions
-
Width x Length
80' " x 77' "
-
Height
34'-3
-
Stories
2/
Garage
-
Number of Cars
3
-
Attached
No
-
Location
Right
Wall Construction
-
Interior
Metal Stud
-
Exterior
CMU Block
-
Insulation
-
CMU Wall
R-4.1
-
Wood Wall
R-19
-
Framed Wall
R-11
Bedrooms
-
Actual
6
-
Possible
0
-
Total
6
Bathrooms
-
Full
7
-
Half
1
-
Total
7
Elevation
-
Finishes
Stucco
-
Master Bedroom Location
2
-
Utility Location
1
Features
-
Fireplace
Yes
-
Elevator
Yes
-
Pool
Yes
Instant Download Only
1 Study Set Price: $150
PDF Files Price: $2000
CAD Disk Price: $3000
Reverse PDF Price: $2250
Reverse CAD Price: $3250
Study Set Reverse Price: $200
Hard Copies (Shipped)
Base Price: $1500
3 Sets Price: $1600
5 Sets Price: $1700
8 Sets Price: $1850
Reproducible Vellum Price: $2000
Base – Not for Construction Price: $1500
3 Sets (Reverse) Price: $1950
5 Sets (Reverse) Price: $1950
8 Sets (Reverse) Price: $2100
Reproducible Vellum (Reverse) Price: $2250
Foundation Type
-
Type
stem wall / concrete slab
-
Option
0
Floor System
-
Type
supranos
-
Spacing
0
-
Subfloor
0
-
Thickness
17
Roof System
-
Type
wood trusses
-
Options
0
Additional Information
-
Roof Pitch
5:12
-
Roof: Live Load
30
-
Roof: Dead Load
25
-
Floor: Live Load
40
-
Floor: Dead Load
25
-
Roof Material
S. Tile
-
Wind Speed
140
First Floor
-
Primary Living
21'-6
-
Secondary Living
10'
-
Primary Bedrooms
10'
-
Secondary Bedrooms
10'
-
Bathrooms
10'
-
Common Areas
10'
Second Floor
-
Primary Bedrooms
10' to 11'-4
-
Secondary Bedrooms
10'
-
Bathrooms
9'-6
-
Common Areas
10'
Exterior
-
Garage
9'-1
-
Covered Entry
27'-8
-
Covered Patio
10'-6
-
Covered Balcony
10'-6
Total AC Sq Ft
-
First Floor AC
3539
-
Second Floor AC
3140
-
Total AC
6679
Total Under Roof Sq Ft
-
Garage
965
-
Covered Entry
84
-
Covered Patio
626
-
Covered Balconies
322
-
Total Under Roof
8676
