PLAN SUMMARY
-
Stories
2
-
Bedrooms
6
-
Bathrooms
7
-
Garage
3 car
-
Width x Length:
90' 5" x 78' "
-
First Floor Sq Ft
3,929 Sq. Ft.
-
Second Floor Sq Ft
3,172 Sq. Ft.
-
Total AC Sq Ft
7,100 Sq. Ft.
-
Total Under Roof Sq Ft
9,574 Sq. Ft.
$0.00
Plan Description
Beautiful Spanish-influenced 7,100 sq. ft. home floor plan features a beautiful yet bold entrance, six bedrooms, seven and one-half bathrooms, an ultimate combination of tradition and opulent amenities of modern living. An impressive grand foyer leads you to a large living room with a regal fireplace crowned by stepped ceilings. The peninsula kitchen features an eat-in bar facing the family room, a breakfast nook that lets in the sun and a formal dining room. This is truly a well thought-out design offering a maid’s room and utility room adjacent to a spacious three-car garage. A striking stair tower and artistic elements of this design make it “fit for a king.” This home floor plan is filled with every amenity imaginable and architectural features including expansive covered patios with a summer kitchen, luxurious master suite that monopolizes an entire wing of the second story with a private sitting area and covered balcony. Additional amenities are a library, media room and a large guest suite with a private entrance. If you seek architectural elegance on a grand scale, this home is for you! Get this house floor plan today.
Dimensions
-
Width x Length
90' 5" x 78' "
-
Height
33'-4
-
Stories
2/
Garage
-
Number of Cars
3
-
Attached
No
-
Location
Left
Wall Construction
-
Interior
Metal stud
-
Exterior
CMU
-
Insulation
-
CMU Wall
R-4.1
-
Wood Wall
R-19
-
Framed Wall
R-11
Bedrooms
-
Actual
6
-
Possible
0
-
Total
6
Bathrooms
-
Full
7
-
Half
1
-
Total
7
Elevation
-
Finishes
Stucco
-
Master Bedroom Location
2
-
Utility Location
2
Features
-
Fireplace
Yes
-
Elevator
Yes
-
Pool
Yes
Instant Download Only
1 Study Set Price: $
PDF Files Price: $
CAD Disk Price: $
Reverse PDF Price: $
Reverse CAD Price: $
Study Set Reverse Price: $
Hard Copies (Shipped)
Base Price: $
3 Sets Price: $
5 Sets Price: $
8 Sets Price: $
Reproducible Vellum Price: $
Base – Not for Construction Price: $
3 Sets (Reverse) Price: $
5 Sets (Reverse) Price: $
8 Sets (Reverse) Price: $
Reproducible Vellum (Reverse) Price: $
Foundation Type
-
Type
Monolithic
-
Option
0
Floor System
-
Type
Epicore
-
Spacing
0
-
Subfloor
0
-
Thickness
0
Roof System
-
Type
Wood trusses
-
Options
0
Additional Information
-
Roof Pitch
5:12
-
Roof: Live Load
30
-
Roof: Dead Load
25
-
Floor: Live Load
40
-
Floor: Dead Load
25
-
Roof Material
C. tile
-
Wind Speed
140
First Floor
-
Primary Living
21'-6
-
Secondary Living
9'-9
-
Primary Bedrooms
0
-
Secondary Bedrooms
9-9
-
Bathrooms
9'-1
-
Common Areas
9'-1
Second Floor
-
Primary Bedrooms
10'-10
-
Secondary Bedrooms
10'
-
Bathrooms
10'
-
Common Areas
10'
Exterior
-
Garage
11'-1
-
Covered Entry
22'
-
Covered Patio
10'-3
-
Covered Balcony
0
Total AC Sq Ft
-
First Floor AC
3929
-
Second Floor AC
3172
-
Total AC
7100
Total Under Roof Sq Ft
-
Garage
641
-
Covered Entry
201
-
Covered Patio
806
-
Covered Balconies
826
-
Total Under Roof
9574
